P256

Ro Pax

Owner / Shipname
Stena RORO - Operator: Balearia / Borja Dos - Dimonios
IMO Number
9349772
Class
RINA C Ro Ro Passenger Ship, Unrestricted Navigation, AUT UMS Ice Class – 1A
Yard / Number
Cantiere Navale Visentini / NB 218
Main Particulars
LOA 186,50 m
LBP 177,40 m
BOA 25,60 m
Design draught 6,70 m
DWT abt 7.000 t
Loading Capacities/Free Height
Lower hold: 258 lm - Free heigth 4.335 m
Car Deck 2 - Free height 1.955 m
Main deck : 886 lm - Free height 4.887 m
Weather Deck (+fixed ramp) 1.112 lm / Free height 5.112 m
Car Deck
Deck 2 : no.cars 83
Deck 5 : no.cars 118
Accomodation
Passenger cabins (2+2) : 120
Disabled cabins (1+1) : 1
Crew cabins : 31
Avion seats : 36
Machinery
Main Engines: 2 x 10.800 kW each 500 RPM
Auxiliaries: Diesel generators 1.800 kW each
Propellers: 2 - Diameter 4,8 m
Bow thrusters: 2 x 1.300 kW each
Fin stabilizers
Speed
Service speed : 24 kn
Tank Capacities
Heeling tanks : 792 m³
FW : 376 m³
MDO : 335 m³
WB : 5.965 m³
HFO : 1.473 m³
Supply
GA Plans, class drawings, workshop drawings
Stability according to Solas, Stockolm Agreement
